光伏及储能系统：集成光伏和储能系统调制解调器，支持多块电池，与EMS智能能源管理系统集成；
智能切换：UPS功能，支持三相不平衡，10ms内开启/关闭电网；
宽电压输入范围：宽光伏电压输入范围180V-900V。宽电池电压范围180V-700V；
安全可靠：IP65防护等级，铝制外壳，内置防雷保护，高精度漏电保护；
Technical Parameter
技术参数
| 产品型号 | HJ-IH30-W500T（A-16） | HJ-IH30-W500T（A-20） | HJ-IH40-W500T（A-17） | HJ-IH40-W500T（A-21） | HJ-IH50-W500T（A-18） | HJ-IH60-W500T（A-19） |
| 光伏输入数据 | ||||||
| 最大输入功率 | 45000W | 45000W | 60000W | 60000W | 75000W | 90000W |
| 最大输入电压 | 1000V | 1000V | 1000V | 1000V | 1000V | 1000V |
| MPPT工作电压范围 | 180-900V | 180-900V | 180-900V | 180-900V | 180-900V | 180-900V |
| 启动电压 | 180V | 180V | 180V | 180V | 180V | 180V |
| 最大输入电流 | 36A/36A/36A | 36A/36A/36A | 36A/36A/36A/36A | 36A/36A/36A/36A | 36A/36A/36A/36A | 36A/36A/36A/36A |
| 最大短路电流 | 42A/42A/42A | 42A/42A/42A | 42A/42A/42A/42A | 42A/42A/42A/42A | 42A/42A/42A/42A | 42A/42A/42A/42A |
| MPPT跟踪器数量 | 3 | 3 | 4 | 4 | 4 | 4 |
| 每个MPPT的串数 | 2/2/2 | 2/2/2 | 2/2/2/2 | 2/2/2/2 | 2/2/2/2 | 2/2/2/2 |
| 电池输入数据 | ||||||
| 电池电压范围 | 220-800V | 220-800V | 220-800V | 220-800V | 220-800V | 220-800V |
| 最大充电/放电电流 | 100A/100A | 100A/100A | 100A/100A | 100A/100A | 100A/100A | 100A/100A |
| 最大充电/放电功率 | 30000W/30000W | 30000W/30000W | 40000W/40000W | 40000W/40000W | 50000W/50000W | 60000W/60000W |
| 电池类型 | Li-ion/Lead-acid | Li-ion/Lead-acid | Li-ion/Lead-acid | Li-ion/Lead-acid | ||
| 交流输出数据（并网） | ||||||
| 额定输出功率 | 30000W | 30000W | 40000W | 40000W | 50000W | 60000W |
| 最大视在功率 | 30000VA | 30000VA | 40000VA | 40000VA | 50000VA | 60000VA |
| 额定输出电压 | 380V400V,3L/N/PE | 380V400V,3L/N/PE | 380V/400V, 3LN+PE | 380V/400V, 3LN+PE | 380V/400V, 3LN+PE | 380V/400V, 3LN+PE |
| 额定输出频率 | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz |
| 最大输出电流 | 45A | 45A | 60A | 60A | 75A | 90A |
| 功率因数 | ~1(0.8 lead to 0.8 lag can be set) | ~1(0.8 lead to 0.8 lag can be set) | -1 (0.8 lead to 0.8 lag can be set) | -1 (0.8 lead to 0.8 lag can be set) | -1 (0.8 lead to 0.8 lag can be set) | -1 (0.8 lead to 0.8 lag can be set) |
| 总谐波失真 | <3% | <3% | <3% | <3% | <3% | <3% |
| 交流输出数据（备用） | ||||||
| 额定输出功率 | 30000W | 30000W | 40000W | 40000W | 50000W | 60000W |
| 最大视在功率 | 30000VA | 30000VA | 40000VA | 40000VA | 50000VA | 60000VA |
| 额定输出电压 | 380V400V,3L/N/PE | 380V400V,3L/N/PE | 380V/400V, 3LN+PE | 380V/400V, 3LN+PE | 380V/400V, 3LN+PE | 380V/400V, 3LN+PE |
| 额定输出频率 | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz |
| 最大输出电流 | 45A | 45A | 60A | 60A | 75A | 90A |
| 效率 | ||||||
| 最大效率 | 98.40% | 98.40% | 0.984 | 0.984 | 98.40% | 98.40% |
| 欧洲效率 | 97.50% | 97.50% | 0.975 | 0.975 | 97.50% | 97.50% |
| 保护功能 | ||||||
| 交流过电流保护 | Integrated | Integrated | Integrated | Integrated | Integrated | Integrated |
| 接地故障保护 | Integrated | Integrated | Integrated | Integrated | Integrated | Integrated |
| 电源网络监控 | Integrated | Integrated | Integrated | Integrated | Integrated | Integrated |
| 剩余电流监控 | Integrated | Integrated | Integrated | Integrated | Integrated | Integrated |
| 基础参数 | ||||||
| 工作温度范围 | -25°C-60°C (>45°C Derating) | -25°C-60°C (>45°C Derating) | -25°C-60°C (>45°C Derating) | -25°C-60°C (>45°C Derating) | -25°C-60°C (>45°C Derating) | -25°C-60°C (>45°C Derating) |
| 海拔高度 | ≤4000m | ≤4000m | ≤4000m | ≤4000m | ≤4000m | ≤4000m |
| 噪声排放 | <40dB | <40dB | <40dB | <40dB | <40dB | <40dB |
| 拓扑结构 | Transformerless Isolation | Transformerless Isolation | Transformerless Isolation | Transformerless Isolation | Transformerless Isolation | Transformerless Isolation |
| 散热方式 | Intelligent Fan | Intelligent Fan | Intelligent Fan | Intelligent Fan | Intelligent Fan | Intelligent Fan |
| 防护等级 | IP54 | IP65 | IP54 | IP65 | IP54 | IP54 |
| 相对湿度 | 0-90% (No Condensation) | 0-90% (No Condensation) | 0-90% (No Condensation) | 0-90% (No Condensation) | 0-90% (No Condensation) | 0-90% (No Condensation) |
| 直流连接器类型 | MC4/Anderson Powerpole | MC4/Anderson Powerpole | MC4/Anderson Powerpole | MC4/Anderson Powerpole | MC4/Anderson Powerpole | MC4/Anderson Powerpole |
| 交流连接器类型 | Plug-in Connector | Plug-in Connector | Plug-in Connector | Plug-in Connector | Plug-in Connector | Plug-in Connector |
| 显示屏 | LCD | LCD | LCD | LCD | LCD | LCD |
| 云通信 | RS485 (WIFI/GPRS optional) | RS485 (WIFI/GPRS optional) | RS485 (WIFI/GPRS optional) | RS485 (WIFI/GPRS optional) | RS485 (WIFI/GPRS optional) | RS485 (WIFI/GPRS optional) |
| BMS通信模式 | CAN | CAN | CAN | CAN | CAN | CAN |
| 与电表通信 | RS485 | RS485 | RS485 | RS485 | RS485 | RS485 |
| 安装 | 壁挂/落地 | 壁挂/落地 | 壁挂/落地 | 壁挂/落地 | 壁挂/落地 | 壁挂/落地 |
| 空载自用电量 | <10W | <10W | <10W | <10W | <10W | <10W |
| 尺寸（宽×深×高） | 800×350×875mm | 800×350×875mm | 800×350×875mm | 800×350×875mm | 800×350×875mm | 800×350×875mm |
| 重量 | 102kg | 102kg | 102kg | 102kg | 102kg | 102kg |
| 认证 | ||||||
| 安全标准 | IEC62109-1-2 | IEC62109-1-2 | IEC62109-1/2 | IEC62109-1/2 | IEC62109-1/2 | IEC62109-1/2 |
| 电磁兼容性标准 | EN 61000-6-1, -2, -3, -4 | EN 61000-6-1, -2, -3, -4 | EN 61000-6-1, -2, -3, -4 | EN 61000-6-1, -2, -3, -4 | EN 61000-6-1, -2, -3, -4 | EN 61000-6-1, -2, -3, -4 |
| 并网标准 | AS4777.2:2000, NRS097-2-1:2017, EN50649-1:2019, VDE-AR-N 4105:2018 | AS4777.2:2000, NRS097-2-1:2017, EN50649-1:2019, VDE-AR-N 4105:2018 | AS4777.2:2010, NRS097-2-1:2017, EN50649-1:2019, VDE-AR-N 4105:2018 | AS4777.2:2010, NRS097-2-1:2017, EN50649-1:2019, VDE-AR-N 4105:2018 | AS4777.2:2010, NRS097-2-1:2017, EN50649-1:2019, VDE-AR-N 4105:2018 | AS4777.2:2010, NRS097-2-1:2017, EN50649-1:2019, VDE-AR-N 4105:2018 |
